Olivetti M20 technical specifications:
|
Processor:
|
Zilog Z8001
|
Clock speed:
|
4MHz
|
RAM:
|
128KiB expandable up to 512KiB
|
ROM:
|
8KiB containing the startup and boot program
|
Operating systems:
|
PCOS, CP/M8000, MS-DOS (with the APB 8086 card)
|
Screen:
|
B/W, Green, Amber, 4 or 8 colors
|
Graphic resolution:
|
512x256 pixels
|
Text layout:
|
80x25 or 64x16 characters
|
Disk drives:
|
One or two 160KiB-320KiB-640KiB on 5"1/4 drives
|
Hard disk:
|
Optional 11.5MiB Winchester
|
| Installed interfaces: |
RS232 and Parallel (Centronics), with proprietary connectors |
| Optional interfaces: |
Double RS232 (normal and current-loop) and IEEE488 |
|
